PTFE SUCTION HOSE WITH PP BRAIDING

A PTFE Suction Hose with PP Braiding is a lightweight, flexible, and chemically resistant hose designed primarily for suction and low-pressure transfer of corrosive chemicals, acids, solvents, and other aggressive fluids. The PTFE liner ensures maximum chemical compatibility, while the polypropylene braided reinforcement provides strength without adding much weight or affecting corrosion resistance.

Key Features:

Inner Tube: Virgin PTFE (Smooth or Corrugated bore)

Outer Braid: Woven Polypropylene (PP)

Temperature Range: –40°C to +100°C (max. 120°C short duration)

Pressure Rating: Typically up to 6–10 bar depending on size

Vacuum Capability: Suitable for full vacuum (when spiral reinforced)

Non-Conductive: Ideal for non-metallic, non-reactive environments
